SPECS

W X D X H 25.59 X 24.40 X 34.84 inch

Weight 72kg(159lb)

Maximum Bean Input Weight 850g(1.87lb)

Electrical Output 3.5kW

Hot Blast Heater 2kW

Halogen 1.5kW

Stirring Wings Motor 25W

  • User-friendly touchscreen interface
  • 10.1” display
  • Sensors (Internal/Tower Drum/Hot Air/Exhaust temp)
  • 20 level discrete control over convection and radiation heat
  • ROR & DTR display
  • Automatic profile data logging
  • Manual/Program mode
  • Profile Auto Replication
  • Safety Features (emergency discharge, automatic shutdown, etc.)
  • Fast cooling (Room temperature in 1.5 min)
  • Automatic system upgrade (Android OS)

EXTERIOR

DETAILS

Tower Drum Sensor

Placed inside the 5 layer drum structure, it measures temperature of the drum wall in contact with the beans.

Halogen Lamps

Radiation heat emitted from the halogen lamps directly penetrates the beans and allows uniform heating even at the core.

Tower Drum Structure

5 layer insulated steel drum structure is designed to readily react to heat controls and minimize heat loss with superior quality and durability.

Internal Sensor

Placed at the bottom, it measures internal temperature and the bean temperature while roasting.

Hot Air Sensor

Measures temperature of the hot air blown into the drum.

Tower Drum (Stirring Wing Structure)

Minimizes heat loss by rotating stirring wings inside the vertical drum rather than rotating the drum itself.

Cooling Fan

Cools the discharged beans by absorbing air through the bean. It takes 1.5 – 2 minutes to reach room temperature.

Hot Air Blower

Hot air is blown into the drum and circulated evenly throughout the beans.

Exhaust Sensor

Measures exhaust temperature out of the drum.

Cyclone

Collects the chaff into the chaff box.

TO BE FURTHER UPDATED

To be updated,

further.
